Knuckle Joint High Speed Press Machine
Technical parameter

Specifications Unit MARX-30T MARX-40T MARX-60T MARX-80T
Press capacity Ton 30 40 60 80
Slider stroke length mm 16 20 25 30 16 20 25 30 20 25 32 40 20 25 32 40
Slider strokes per minute Spm 200-1250 200-1200 200-1050 200-900 180-1250 180-1100 180-950 180-900 100-750 100-750 100-650 100-550 120-600 120-500 120-500 120-450
Die height mm 190-240 190-240 220-300 240-320
Bolster area mm 600*400 750*500 1100*600 1500*800
Slider size mm 600*300 750*340 1130*500 1380*580
Adjustment amount mm 50 50 80 80
Opening size of bolster mm 400（UP)*350(LOW)*60 500*100 800(UP)*700(LOW)*100 1160(UP)*1160(LOW)*120
Main motor KW 11 15 22 30
Total weight Kg 6500 8000 14000 22000
